Aluminum Scrap Shavings Recycling Crusher
Structural Composition：
1. Feed system: usually includes feed silos and conveyors, which are used to transport aluminum shavings smoothly and evenly to the interior of the shredder, and some will be equipped with devices such as electromagnetic vibration feeders to accurately control feed speed and amount.
2. Shredding mechanism: It is the core component, mainly composed of tool shaft, blade, bearing seat, etc. The double-shaft shredder generally has two knife shafts equipped with blades, which are driven by the motor and the reducer, and the blades mesh with each other to shear, shred and extrude the steel shavings; The single-shaft shredder relies on the blade on the single shaft and the fixed tool holder to complete the shredding work.
3. Power system: composed of motor, reducer, coupling, etc., to provide power for the shredder, so that the tool shaft can rotate at the appropriate speed and torque to meet the shredding needs of different aluminum shavings.
4. Discharge system: including the discharge port and the discharge conveyor, etc., to transport the shredded aluminum shaver pieces to the designated location for subsequent collection, transportation or further processing.
5. Control system: PLC program control system, can realize the equipment start, stop, positive and negative rotation and overload protection and other functions, some also have remote monitoring and fault diagnosis functions, easy operation and maintenance.
Working Principle:
Generally through the motor operation, the power is transmitted to the cutter shaft through the reducer, so that the cutter shaft drives the blade to rotate at high speed. When the aluminum shavings enter the machine, under the force of the high-speed rotating blade, the cutting edge of the adjacent knife face on the knife shaft forms shear, the cutting edge of the knife tip and the bottom knife cylinder form shear, and the torque and speed difference of the knife shaft form shredding, which will shred the aluminum shavings into particles or small blocks and discharge them from the discharge port at the bottom or side of the machine.
Equipment Characteristics:
1. Tool durability: The blade is usually made of high hardness, high strength alloy tool steel or wear-resistant die steel, after special heat treatment process, has good wear resistance, toughness and impact resistance, can withstand long-term high strength work, long service life.
2. High torque and low speed: The design of low speed and high torque can output strong shredding force and effectively break steel shavings, while avoiding excessive heat generated by high-speed operation, resulting in equipment damage or steel shavings sticking.
3. Intelligent control: Equipped with intelligent control system, it can monitor the operating status of the equipment in real time, such as motor current, tool temperature, material blockage, etc., and automatically alarm and stop protection when abnormal occurs.
Our service and advantage:
1.We have many experience on OEM work.
2.We can customize special specifications as customer demand.
3.Technical service for assembling.
4.Variety types for selection, prompt deliver.
5.Well-equipped with extensive sales network.
6.Advanced Production equipment and production technique.
7.Competitive Price (Factory direct price) with our good service.
8.Different designs are available according to customer requests.
9.Excellent quality testing equipment, 100% inspection on critical .
With the enhancement of global environmental awareness and the growth in demand for resource recycling, Aluminum Scrap Shredder has broad prospects. In emerging markets and developing countries, economic development and the popularization of environmental protection concepts will drive up their demand. From a technical perspective, in the future, Aluminum Shredder will move towards intelligence, efficiency and environmental protection, better aligning with the market. Its application fields will also continue to expand and play a greater role in industries such as new energy vehicles. It can be foreseen that the Aluminum Shredder Machine will continue to make efforts in the fields of environmental protection and resource recycling, and embrace a broader development space.
